You are here: Home Cable Ties and Cable Management Cable Glands and Accessories Cable Glands, Straight


Cable Glands, Straight

Email
19767

Cable Glands provide entry for a cable into and enclosure. With variations in thread size, colour and mounting thread lengths the range supports an array of Cable Gland to suit your application needs.

Sample Part
Number 		Gland Form Thread Size Pitch/TPI Colour Full Material Overall Length O-Ring/Gasket Material Specifications/Standards (All) Operating Temperature Range ATEX Explosion Protection Compatible Cable Diameter Range DIN Protection Class EN Protection Class Material Mounting Thread Length (mm) Width Across Flats
Unit of
Measurements 		Price
(Ex. GST)		 Quantity Total
551807 ATEX Low Voltage M63 1.5 mm Blue Nylon ---- ---- IP68 - 5 Bar -40 to II 2 G Ex e II II 2 D Ex tD A21 IP68 34.0 - 48.0 mm DIN40050-T9 EN60529 Nylon 15.0 mm ----
0.00 ₨
551806 ATEX Low Voltage M50 1.5 mm Blue Nylon ---- ---- IP68 - 5 Bar -40 to II 2 G Ex e II II 2 D Ex tD A21 IP68 23.0 - 25.0 mm DIN40050-T9 EN60529 Nylon 14.0 mm ----
0.00 ₨
551805 ATEX Low Voltage M40 1.5 mm Blue Nylon ---- ---- IP68 - 5 Bar -40 to II 2 G Ex e II II 2 D Ex tD A21 IP68 17.0 - 28.0 mm DIN40050-T9 EN60529 Nylon 12.0 mm ----
0.00 ₨
551804 ATEX Low Voltage M32 1.5 mm Blue Nylon ---- ---- IP68 - 5 Bar -40 to II 2 G Ex e II II 2 D Ex tD A21 IP68 130 - 21.0 mm DIN40050-T9 EN60529 Nylon 12.0 mm ----
0.00 ₨
551803 ATEX Low Voltage M25 1.5 mm Blue Nylon ---- ---- IP68 - 5 Bar -40 to II 2 G Ex e II II 2 D Ex tD A21 IP68 7.0 - 17.0 mm DIN40050-T9 EN60529 Nylon 10.0 mm ----
0.00 ₨
551802 ATEX Low Voltage M20 1.5 mm Blue Nylon ---- ---- IP68 - 5 Bar -40 to II 2 G Ex e II II 2 D Ex tD A21 IP68 6.0 - 13.0 mm DIN40050-T9 EN60529 Nylon 10.0 mm ----
0.00 ₨
551801 ATEX Low Voltage M16 1.5 mm Blue Nylon ---- ---- IP68 - 5 Bar -40 to II 2 G Ex e II II 2 D Ex tD A21 IP68 4.0 - 9.0 mm DIN40050-T9 EN60529 Nylon 9.0 mm ----
0.00 ₨
551800 ATEX M63 1.5 mm Black Nylon ---- ---- IP68 - 5 Bar -40 to II 2 G Ex e II II 2 D Ex tD A21 IP68 34.0 - 48.0 mm DIN40050-T9 EN60529 Nylon 15.0 mm ----
0.00 ₨
551799 ATEX M50 1.5 mm Black Nylon ---- ---- IP68 - 5 Bar -40 to II 2 G Ex e II II 2 D Ex tD A21 IP68 23.0 - 25.0 mm DIN40050-T9 EN60529 Nylon 14.0 mm ----
0.00 ₨
551798 ATEX M40 1.5 mm Black Nylon ---- ---- IP68 - 5 Bar -40 to II 2 G Ex e II II 2 D Ex tD A21 IP68 17.0 - 28.0 mm DIN40050-T9 EN60529 Nylon 12.0 mm ----
0.00 ₨
551797 ATEX M32 1.5 mm Black Nylon ---- ---- IP68 - 5 Bar -40 to II 2 G Ex e II II 2 D Ex tD A21 IP68 13.0 - 21.0 mm DIN40050-T9 EN60529 Nylon 12.0 mm ----
0.00 ₨
551796 ATEX M25 1.5 mm Black Nylon ---- ---- IP68 - 5 Bar -40 to II 2 G Ex e II II 2 D Ex tD A21 IP68 7.0 - 17.0 mm DIN40050-T9 EN60529 Nylon 10.0 mm ----
0.00 ₨
551795 ATEX M20 1.5 mm Black Nylon ---- ---- IP68 - 5 Bar -40 to II 2 G Ex e II II 2 D Ex tD A21 IP68 6.0 - 13.0 mm DIN40050-T9 EN60529 Nylon 10.0 mm ----
0.00 ₨
551794 ATEX M16 1.5 mm Black Nylon ---- ---- IP68 - 5 Bar -40 to II 2 G Ex e II II 2 D Ex tD A21 IP68 4.0 - 9.0 mm DIN40050-T9 EN60529 Nylon 9.0 mm ----
0.00 ₨
551793 ATEX M63 1.5 mm Steel Stainless Steel A2 ---- EPDM IP68 - 5 Bar -40 to II 2 G Ex e II II 2 D Ex tD A21 IP68 34.0 - 48.0 mm DIN40050-T9 EN60529 Stainless Steel 10.0 mm ----
0.00 ₨
551792 Standard M50 1.5 mm Steel Stainless Steel A2 ---- EPDM IP68 - 5 Bar -40 to ---- 21.0 - 35.0 mm DIN40050-T9 EN60529 Stainless Steel 9.0 mm ----
0.00 ₨
551791 Standard M40 1.5 mm Steel Stainless Steel A2 ---- EPDM IP68 - 5 Bar -40 to ---- 16.0 - 28.0 mm DIN40050-T9 EN60529 Stainless Steel 8.0 mm ----
0.00 ₨
551790 Standard M32 1.5 mm Steel Stainless Steel A2 ---- EPDM IP68 - 5 Bar -40 to ---- 13.0 - 21.0 mm DIN40050-T9 EN60529 Stainless Steel 8.0 mm ----
0.00 ₨
551789 Standard M25 1.5 mm Steel Stainless Steel A2 ---- EPDM IP68 - 5 Bar -40 to ---- 9.0 - 17.0 mm DIN40050-T9 EN60529 Stainless Steel 7.0 mm ----
0.00 ₨
551788 Standard M20 1.5 mm Steel Stainless Steel A2 ---- EPDM IP68 - 5 Bar -40 to ---- 6.0 - 13.0 mm DIN40050-T9 EN60529 Stainless Steel 6.0 mm ----
0.00 ₨
551787 Standard M16 1.5 mm Steel Stainless Steel A2 ---- EPDM IP68 - 5 Bar -40 to ---- 4.5 - 10.0 mm DIN40050-T9 EN60529 Stainless Steel 5.0 mm ----
0.00 ₨
551786 Standard M12 1.5 mm Steel Stainless Steel A2 ---- EPDM IP68 - 5 Bar -40 to ---- 3.0 - 7.0 mm DIN40050-T9 EN60529 Stainless Steel 5.0 mm ----
0.00 ₨
551244 EMC M40 1.5 mm Brass Nickel-Plated Brass 55.0 mm ---- ---- ---- ---- 16.0 - 28.0 mm ---- ---- Brass 8.0 mm 46.0 mm
0.00 ₨
551243 EMC M32 1.5 mm Brass Nickel-Plated Brass 44.0 mm ---- ---- -20 to ---- 13.0 - 21.0 mm ---- ---- Brass 8.0 mm 36.0 mm
0.00 ₨
551242 EMC M25 1.5 mm Brass Nickel-Plated Brass 42.0 mm ---- ---- -20 to ---- 9.0 - 17.0 mm ---- ---- Brass 7.0 mm 29.0 mm
0.00 ₨
551241 EMC M20 1.5 mm Brass Nickel-Plated Brass 37.0 mm ---- ---- -20 to ---- 6.0 - 13.0 mm ---- ---- Brass 6.0 mm 24.0 mm
0.00 ₨
551240 EMC M16 1.5 mm Brass Nickel-Plated Brass 34.0 mm ---- ---- -20 to ---- 4.5 - 10.0 mm ---- ---- Brass 6.0 mm 20.0 mm
0.00 ₨
551239 EMC M40 1.5 mm Brass Nickel-Plated Brass 30.0 mm ---- ---- -20 to ---- ---- ---- ---- Brass 5.0 mm 46.0 mm
0.00 ₨
550944 Multi Slot M40 1.5 mm Black Nylon 65.0 mm EPDM IP68 - 5 Bar -40 to ---- 16.0 - 28.0 mm ---- ---- Nylon 12.0 mm ----
0.00 ₨
550943 Multi Slot M40 1.5 mm Grey Nylon 65.0 mm EPDM ---- -40 to ---- 16.0 - 28.0 mm ---- ---- Nylon 12.0 mm ----
0.00 ₨
550938 Multi Slot M32 1.5 mm Black Nylon 51.0 mm EPDM ---- -40 to ---- 13.0 - 21.0 mm ---- ---- Nylon 10.0 mm ----
0.00 ₨
550937 Multi Slot M32 1.5 mm Grey Nylon 51.0 mm EPDM ---- -40 to ---- 13.0 - 21.0 mm ---- ---- Nylon 10.0 mm ----
0.00 ₨
550931 Multi Slot M25 1.5 mm Black Nylon 47.0 mm EPDM ---- -40 to ---- 9.0 - 17.0 mm ---- ---- Nylon 10.0 mm ----
0.00 ₨
550930 Multi Slot M25 1.5 mm Grey Nylon 47.0 mm EPDM ---- -40 to ---- 9.0 - 17.0 mm ---- ---- Nylon 10.0 mm ----
0.00 ₨
550924 Multi Slot M20 1.5 mm Black Nylon 45.0 mm EPDM ---- -40 to ---- 6.0 - 13.0 mm ---- ---- Nylon 10.0 mm ----
0.00 ₨
550923 Multi Slot M20 1.5 mm Grey Nylon 45.0 mm EPDM ---- -40 to ---- 6.0 - 13.0 mm ---- ---- Nylon 10.0 mm ----
0.00 ₨
550918 Multi Slot M20 1.5 mm Black Nylon 45.0 mm EPDM ---- -40 to ---- 6.0 - 13.0 mm ---- ---- Nylon 10.0 mm ----
0.00 ₨
550917 Multi Slot M16 1.5 mm Grey Nylon 37.0 mm EPDM ---- -40 to ---- 4.5 - 10.0 mm ---- ---- Nylon 9.0 mm ----
0.00 ₨
550912 Multi Slot M12 1.5 mm Black Nylon 34.0 mm EPDM ---- -40 to ---- 3.0 - 7.0 mm ---- ---- Nylon 9.0 mm ----
0.00 ₨
550911 Multi Slot M12 1.5 mm Grey Nylon 34.0 mm EPDM ---- -40 to ---- 3.0 - 7.0 mm ---- ---- Nylon 9.0 mm ----
0.00 ₨
